Coolbreeze Heritage Evaporative Air Conditioning Series

black heritage coolbreeze evaporative cooler

CoolBreeze Heritage evaporative air conditioning is a stylish air-con that compliments any roof and will add value to your home. With only the highest quality materials, and an abundance of research into how to make your evaporative air conditioner perform to the highest standard, we know you’ll be incredibly impressed with the latest models of the Coolbreeze Heritage range.

Product Specificatons

Model KW* Cooling Capacity Airflow
(Litre/sec @
60Pa)**
Motor Size
(watts)
Height
(mm)
D095  8 95 1950 600 490
D125 10.2 125 2100 600 580
D160 12.7 160 2350 750 580
D195 15.2 195 2800 1000 655
D230 16.7 230 2900 1000 770
D255 17.7 255 3000 1000 890

* Airflow tested in accordance with ISO5801: Fan performance testing utilising standardised airways. KW capacities calculated according to AS2913-2000 under standardised conditions, inlet dry bulb temp 38o, inlet wet bulb temp 21o and comfort dry bulb temp27.4o. Calculations based on air flow test as per CSIRO report 00/228 and Saturation Efficiency test as per CSIRO report 90/16m.

** AirGroup Australia pursues a policy of continuous development and therefore reserves the right to make product changes without notice. Evaporative air-conditioning cooling performance reduces during high humidity. Installation and commissioning to manufacturers specifications, industry standards and State regulations is the responsibility of the installer. Pictures for illustration purposes only. Always refer to your quotation for specific details of products.

Is Evaporative Cooling Quiet?

Evaporative cooling makes other cooling units inferior when you compare their operation noise levels. The 3 layer Air Conditioning Ducting has improved acoustic quality tested to AS 1277-1983. It absorbs up to 75% of sound in comparison to standard ducts. A Dropper Chute also provides less noise – up to 7dBa quieter.

Air conditioning ducting on the right and dropper chute on the left

Does Evaporative Cooling distribute the air evenly around the home?

The use of Ezyvent Ceiling Diffusers allows for maximum even distribution of air throughout the home that is possible. A 15% increase in air flow is also achievable with a Dropper Chute.

weather seal option with description for coolbreeze evaporative cooler

Since Evaporative Cooling involves the pull of outside air into my home, does this mean my home will be exposed to the outside elements?

Weather Seal is an additional option for customers that prevents drafts and heat escaping during the winder months.

Ezyvent Ceiling Diffuser for coolbreeze evaporative cooling

Do I have to keep windows and doors open all the time when using evaporative cooling?

A Security Vent/Air Relief Vent  is an additional option for your Evaporative Cooling Unit that insulates between the roof and the ceiling relieving air into the ceiling space. This allows you to operate your unit with doors and windows closed.

security vent/air relief vent as an additional option for coolbreeze evaporative coolers
front page of the coolbreeze brochure PDF download
front page of the coobreeze general specifications and product description PDF
Front page of the owners guide for CoolBreeze evaporative cooling units aNd the QM and QA CONTROLLERS

Coolbreeze Residential Brochure 2015
Download PDF

Coolbreeze Technical Specs
Download PDF

Coolbreeze User Guide QA & QM
Download PDF
